DALI-2 Explained: How the IEC 62386 Standard Is Reshaping Commercial LED Dimming

The lighting industry has spent the better part of two decades moving away from analog dimming. What began as a protocol for fluorescent ballasts has evolved into a comprehensive digital standard that now governs everything from individual LED drivers to occupancy sensors and wall controllers. That standard is DALI-2, and it sits at the core of most modern commercial lighting specifications.

DALI stands for Digital Addressable Lighting Interface. The original DALI, now referred to as DALI version-1, was defined in the IEC 62386 series and focused almost exclusively on control gear — the ballasts and drivers that actually power the lamps. It was a significant step forward from 0–10V analog systems because each device on the bus could be individually addressed, allowing per-fixture control rather than zone-level dimming. But version-1 had limitations. It did not formally standardize control devices such as sensors and switches, which meant those components often relied on proprietary extensions that undermined interoperability between manufacturers.

DALI-2, formally published as the second edition of IEC 62386, addresses that gap directly. The standard is organized into numbered parts. Part 101 covers general requirements for system components, including the bus power supply, wiring, and safety. Part 102 defines the general requirements for control gear. Parts 201 through 209 specify particular device types — part 207, for example, covers LED drivers with single-channel intensity control (commonly called DT6), while part 209 covers LED drivers with color control (DT8), which includes tunable white and RGB output. The 300-series parts, introduced with DALI-2, define control devices: input devices like wall switches and occupancy sensors, as well as application controllers that coordinate system behavior.

At the electrical level, a DALI bus is remarkably simple. It uses two unshielded wires that are polarity-insensitive, meaning a technician does not need to observe positive and negative when terminating devices. The bus operates at a nominal 16 V DC, with an allowed operational window between 11.5 V and 20.5 V. A dedicated bus power supply maintains this voltage and limits the short-circuit current to 250 mA. Each standard control gear draws approximately 2 mA from the bus, so a single line can theoretically support well over 64 devices — but the standard caps the number of short addresses at 64 per line, along with 16 groups and 16 scenes. Cable length is limited to 300 meters when using 1.5 mm² conductors, and the total voltage drop along the line must not exceed 2 V.

What makes DALI genuinely useful, though, is not the wiring but the communication protocol. Every forward frame sent by a controller contains an address byte and an opcode byte. The address byte can target a single device (short address 0–63), a group (0–15), or all devices simultaneously via broadcast. The opcode specifies the action — recall a scene, set a fade time, go to a specific arc power level, or query the device's status. DALI supports 254 arc power levels (1 through 254), with level 255 reserved as MASK or off. The dimming curve is logarithmic, which is deliberate: human perception of brightness is nonlinear, so a logarithmic mapping produces perceptually even steps across the full range. This is one reason DALI systems feel smoother than analog 0–10V systems, which typically use a linear relationship between control voltage and light output.

DALI-2 also introduced several practical improvements over version-1. Fade times were extended from the original range to cover 0.1 seconds up to 16 minutes, allowing for everything from quick on/off transitions to slow architectural cross-fades. Bus-powered control devices are now formally supported, meaning sensors and switches can draw their operating power directly from the DALI bus without needing a separate mains connection. The standard also added Continuous Up/Down commands, which let a user hold a button to dim smoothly rather than sending discrete step commands.

For installers and specifiers, the most important aspect of DALI-2 is interoperability. The DALI Alliance (formerly the Digital Illumination Interface Alliance, or DiiA) manages a certification program in which products must pass standardized conformance tests before they can carry the DALI-2 trademark. This means a DALI-2-certified driver from one manufacturer should work reliably with a DALI-2-certified controller from another, at least for the standardized feature set. In practice, projects that specify DALI-2-certified components across the board encounter far fewer compatibility issues than mixed DALI version-1 installations.

That said, DALI-2 is not a universal solution for every project. The bus power supply, controller, and wiring add cost compared to a simple 0–10V system, and commissioning requires software to assign addresses and configure groups and scenes. For small rooms or simple open-plan areas where only zone-level dimming is needed, the extra complexity may be unnecessary. But for commercial offices, hospitality spaces, healthcare facilities, and any environment where individual fixture control, energy monitoring, or integration with building management systems is required, DALI-2 has become the default choice.

A plastic-housed constant-voltage DALI-2 driver fits naturally into this ecosystem. Its digital interface conforms to IEC 62386-101 and -102, and depending on the variant, it may implement DT6 (part 207) for single-channel dimming or DT8 (part 209) for color temperature control. The constant-voltage output makes it suitable for LED strips, linear fixtures, and modular lighting, while the polycarbonate housing — available in both IP20 and waterproof ratings — accommodates both interior and exterior or wet-location installations. When paired with DALI-2-certified sensors and controllers from the same ecosystem, the result is a system that can be specified, installed, and commissioned with a high degree of confidence in interoperability.

In the end, DALI-2's longevity comes down to one thing: it is an open, internationally standardized protocol with a clear governance structure and a certification regime. As lighting continues to merge with building automation and the Internet of Things, that standardization is what allows systems to scale without locking customers into a single vendor's roadmap.
