180W 24V constant voltage LED driver switching power supply waterproof 12V CE/EMC/EMI PF>0.98 EFFICIENCY>88% NCC CAPACITITOR
2.Reasonable price with good quality and best delivery time.
3.We have a strong R & D team to help customer develop new and stable products
4.Certificate:UL,CB report,CE,RoHS,SAA,C-Tick,RCM,TUV,ETL,CCC
5. Fliker free (Low ripple&noise)
6.Hipot≥3750V
7.Full input voltage 100-277V Vac
8.High PFC>0.98 Efficiency>95%
- Warranty(Year):5-Year Lighting solutions service:Lighting and circuitry design, DIALux evo layout, LitePro DLX layout, Agi32 layout, auto CAD layout, Onsite metering, Project Installation
- Place of Origin:Guangdong, China
- Brand Name:Brightstar
- Model Number:MSD-CV-180W
- Output Power:180W
- Output Type:single,dual,triple,...
- Input Voltage:85-265v
- Output Frequency:50/60HZ
- Output Current:7.5A
- Efficiency:88%
- PFC:>0.98
- Warranty:5 years
- Capacitor:Rubycon
- Protection:over-current,over-voltage,short-circuit
- Weight:400g
- Demension:L240*W70*H40 mm
- Output type:single,dual,triple,...
- Certification:CE TUV SAA ETL RoHS
- Product Name:Bright Star
- Luminous Efficacy(lm/w):100
180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88% 180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%180w waterproof led driver CE/EMC/EMI PF>0.98 EFFICIENCY>88%
Item | waterproof constant voltage LED driver | |||
Output Current (DC) | 0-25A | 0-16.6A | 0-11.1A | 0-8.33A |
Output Voltage (DC) | 12V | 24V | 36V | 48V |
Voltage Precision | ±0.5V | ±0.5V | ±0.5V | ±0.5V |
Power | 20W-400W for your choice | |||
Dimmable Function | 1.non-dimmable type 2.dimmable type: a.0-10V 1-10V PWM b. triac c.DALI | |||
Input Voltage (AC) | AC85~265V (50/60Hz) | |||
Power Factor | >0.98 | |||
Efficiency | >90% | |||
Leakage Current | <2.5mA/240V AC | |||
Operating Temperature | -40℃~+50℃ | |||
Working Humidity | 10%~90%RH | |||
Protection | Current Limiting,Over-voltage,Over-load,Short Circuit,Over Temperature | |||
Safety Standard | UL1012,IP67, IEC 61347 -1,IEC61347-2-13,AS/NZS61347-1 | |||
EMC Standard | EN55015,EN61000,EN61547,Class A | |||
Lifespan | >50000 Hours | |||
No Load Power | <1W | |||
Capacitor | Rubycon / Nippon Chemi-Con | |||
Dimming Way | 0-10V,1-10V,PWM | |||
MOSFET | Fairchild | |||
Filler | Silicon Gel | |||
Catalogue
Model Number | Input Voltage | Output Voltage | Output Current | Output Power | Dimmension | Net Weight | IP |
MSD-CV-30W | AC 85-265V | DC 12V | 2.5A | 30W | 150*44*32mm | 0.5Kg | IP67 |
DC 24V | 1.25A | ||||||
DC 36V | 0.83A | ||||||
MSD-CV-60W | AC 85-265V | DC 12V | 5A | 60W | 181*56*35mm | 0.8Kg | IP67 |
DV 24V | 2.5A | ||||||
DC 36V | 1.67A | ||||||
MSD-CV-70W | AC85-265V | DC 12V | 5.83A | 70W | 181*56*35mm | 0.8Kg | IP67 |
DC 24V | 2.91A | ||||||
DC 36V | 1.94A | ||||||
MSD-CV-80W | AC85-265V | DC 12V | 6.67A | 80W | 190*70*40mm | 0.9Kg | IP67 |
DC 24V | 3.33A | ||||||
DC 36V | 2.22A | ||||||
MSD-CV-90W | AC85-265V | DC 12V | 7.5A | 90W | 190*70*40mm | 0.9Kg | IP67 |
DC 24V | 3.75A | ||||||
DC 36V | 2.5A | ||||||
MSD-CV-100W | AC85-265V | DC 12V | 8.33A | 100W | 190*70*40mm | 0.9Kg | IP67 |
DC 24V | 4.17A | ||||||
DC 36V | 2.8A | ||||||
MSD-CV-120W | AC85-265V | DC 12V | 10A | 120W | 220*70*40mm | 1.2Kg | IP67 |
DC 24V | 5A | 210*70*40mm | 0.96Kg | ||||
DC 36V | 3.33A | ||||||
MSD-CV-150W | AC85-265V | DC 12V | 12.5A | 150W | 240*70*40mm | 1.3Kg | IP67 |
DC 24V | 6.25A | 220*70*40mm | 1.2Kg | ||||
DC 36V | 4.17A | 220*70*40mm | 1.2Kg | ||||
MSD-CV-160W | AC85-265V | DC 12V | 13.3A | 160W | 240*70*40mm | 1.3Kg | IP67 |
DC 24V | 6.5A | 220*70*40mm | 1.2Kg | ||||
DC 36V | 4.4A | 220*70*40mm | 1.2Kg | ||||
MSD-CV-180W | AC85-265V | DC 12V | 15A | 180W | 240*70*40mm | 1.3Kg | IP67 |
DC 24V | 7.5A | ||||||
DC 36V | 5A | ||||||
MSD-CV-200W | AC85-265V | DC 12V | 16A | 200W | 240*70*40mm | 1.3Kg | IP67 |
DC 24V | 8.33A | ||||||
DC 36V | 5.56A | ||||||
MSD-CV-240W | AC85-265V | DC 12V | 20A | 240W | 260*90*48mm | 1.5Kg | IP67 |
DC 24V | 10A | ||||||
DC 36V | 6.67A | ||||||
MSD-CV-250W | AC85-265V | DC 12V | 20.83A | 250W | 260*90*48mm | 1.8Kg | IP67 |
DC 24V | 10.4A | ||||||
DC 36V | 7A | ||||||
MSD-CV-300W | AC85-265V | DC 12V | 25A | 300W | 260*90*48mm | 1.8Kg | IP67 |
DC 24V | 12.5A | ||||||
DC 36V | 8.3A | ||||||
MSD-CV-350W | AC85-265V | DC 24V | 14.6A | 350W | 260*90*48mm | 1.9Kg | IP67 |
DC 36V | 9.7A | ||||||
MSD-CV-400W | AC85-265V | DC 24V | 16.6A | 400W | 260*90*48mm | 1.9Kg |
|
DC 36V | 11.1A | ||||||
DC 48V | 8.33A |
Exhibition
Samples checking: sending by Express (DHL / UPS / FEDEX / TNT/EMS)
Bulk production: sending out by cargo shipping / air freight / Express
| MoreProducts |
Waterproof / Non Waterproof LED Driver
Constant Current / Constant Voltage LED Driver
Triac Dimmable / 0-10V Dimmable /DALI LED Driver
| Quality Guarantee |
All the driver have automatic protection of overload, short circuit, temperature,etc.
Guarantee: 1.The warranty period is 5 years.
2.During the time ,if the product have any question ,we can change the same to you.
We can design the product according to your requirement.
